ZA23F28016 Connector For SK200-8 SK200-6E SK200-6 SK210-8 SK220-3 SK220-4 SK235SR SK250-6E SK290-6E
SK200-8 SK200-6E SK200-6 SK210-8 SK220-3 SK220-4 SK235SR SK250-6E SK290-6E Connector ZA23F28016
| Part Name | Connector | Part Number | ZA23F28016 |
| Brand | Kobelco Kobeki | Applicable Model | SK200-8 SK200-6E SK200-6 SK210-8 SK220-3 SK220-4 SK235SR SK250-6E SK290-6E |
Weight: 0.2 kg
Parts Catalog
| ITEM | QTY | PART NUMBER | PART NAME |
| C4 | 4 | ZD12P02900 | O-RING |
| C3-1 | |||
| C4 | |||
| C3-1 | 1 | ZD12P01100 | O-RING |
| C3 | 2 | ZH22X04000 | HYD CONNECTOR |
| C2-1 | 1 | ZD12P01800 | O-RING |
| C2 | 2 | ZH22X08000 | HYD CONNECTOR |
| C1 | 4 | ZA23F28016 | CONNECTION |
| AR | YN12H00012F1 | Hyd, Propel | |
| B4 | 4 | ZD12P02900 | O-RING |
| B3-1 | 1 | ZD12P01800 | O-RING |
| B3 | 2 | ZH22X08000 | HYD CONNECTOR |
| B2-1 | 1 | ZD12P01100 | O-RING |
| B2 | 2 | ZH22X04000 | HYD CONNECTOR |
| B1 | 4 | ZA23F28016 | CONNECTION |
| AR | YN19H00054F1 | Hyd, Swivel | |
| A19 | 2 | YN02H01511D2 | HYDRAULIC HOSE |
| A18 | 4 | PY01P01043D8 | CLIP |
| A17 | 2 | YN02H01511D1 | HYDRAULIC HOSE |
| A16 | 2 | ZX22M08200 | HOSE |
| A15 | 4 | ZW26X08000 | WASHER |
| A14 | 4 | ZW16X08000 | WASHER |
| A13 | 4 | ZS18C08040 | SCREW |
| A12 | 4 | 2418T24324D2 | SPACER |
| A11 | 2 | YN02H01188P1 | CLAMP |
| A10 | 2 | YN02H01187P1 | CLAMP |
| A9 | 10 | PY01P01043D5 | CLIP |
| A8 | 4 | 2420Z1224D4 | HOSE Guard |
| A7 | 2 | ZX23M04250 | HOSE |
| 1 | YN02H01596P1 | TUBE , ASN YN11-49978 | |
| A4 | 1 | YN02H01487P1 | TUBE , BTW YN11-45001 & YN11-49977 |
| 1 | YN02H01595P1 | TUBE , ASN YN11-49978 | |
| A3 | 1 | YN02H01486P1 | TUBE , BTW YN11-45001 & YN11-49977 |
| 1 | YN02H01594P1 | TUBE , ASN YN11-49978 | |
| A2 | 1 | YN02H01485P1 | TUBE , BTW YN11-45001 & YN11-49977 |
| 1 | YN02H01593P1 | TUBE , ASN YN11-49978 | |
| A1 | 1 | YN02H01484P1 | TUBE , BTW YN11-45001 & YN11-49977 |
| AR | YN02H00070F1 | Hyd, Low |
